The GS2900 Premium X-Ray Vehicle Inspection System is a pass-through, non-intrusive vehicle security inspection solution independently developed by GS Automatic Co., Limited.
It is specifically designed for small passenger vehicles and minibuses, enabling rapid detection of concealed threats such as weapons, explosives, narcotics, and smuggled goods without dismantling the vehicle.
Unlike traditional stop-and-search methods, GS2900 allows drivers and passengers to remain inside the vehicle during scanning, significantly improving checkpoint efficiency while maintaining a high level of safety.
The system is widely deployed at customs checkpoints, border inspection ports, parking entrances, road traffic checkpoints, government facilities, and large-scale event venues.
GS2900 adopts advanced high-energy, low-emission X-ray scanning technology with a pass-through design:
Vehicles drive through the scanning channel at a controlled speed
No need for passengers to exit the vehicle
High inspection throughput with minimal traffic congestion
Small footprint with no requirement for additional construction foundations
This design makes GS2900 ideal for locations where speed, safety, and limited installation space are critical.
The system features automatic material identification, allowing operators to clearly distinguish:
Organic materials
Inorganic materials
Dense and hard-to-penetrate metallic objects
This capability helps security personnel quickly identify suspicious items and potential threats hidden within vehicle structures, trunks, and compartments.
GS2900 is fully compliant with international and domestic radiation safety standards, including ANSI 43.17.
Key safety features include:
Extremely low absorbed dose per scan (≤ 0.15 μSv)
Boundary radiation level ≤ 0.5 μSv
No additional radiation shielding required
Integrated environmental cameras to prevent accidental scanning of pedestrians
The system ensures complete radiation safety for drivers, passengers, operators, and nearby personnel.
The GS2900 software platform provides comprehensive system control and inspection tools, including:
Vehicle information list and data query
User account and permission management
Real-time scanning curve display and image playback
Image processing functions:
Color / black & white
Reverse color
Organic / inorganic removal
Highlight / darken
Zoom in / out
Real-time video and image capture (customizable)
Optional integrations:
Automatic License Plate Recognition (ALPR)
Under Vehicle Inspection System (UVIS)
These options allow GS2900 to be deployed as part of a complete vehicle security inspection solution.
Inspection Channel Size: 300 × 300 cm (W × H)
Scanning Speed: 7–10 km/h
Throughput: Up to 200 vehicles/hour
Penetration: 60–65 mm steel (typical)
Line Resolution: 1.2 mm copper wire
X-Ray Generator: 300 kV dual-energy, side illumination
Absorbed Dose: ≤ 0.15 μSv per scan
Power Consumption: Max. 2 kVA
Operator Station: 32-inch 4K curved single console
Operating Temperature: -10°C to 55°C
Operating Humidity: 0% – 90% RH
Storage Temperature: -23°C to 60°C
Power Supply: 220 VAC ±10%, 50 ±3Hz
(Optional: 100VAC / 110VAC / 120VAC / 200VAC)
Customs and border control vehicle inspection
Road traffic checkpoints
Government and military facility entrances
Parking lot and controlled-access areas
Large-scale event security checkpoints
